The TCM0J106M8R is a high-quality, surface-mount tantalum capacitor from KYOCERA AVX's TC series. Offering stable performance in a compact 0603 (1608 metric) package, it is ideal for applications requiring reliable decoupling and noise suppression in space-constrained designs.
Features
- Capacitance: 10 µF ±20%
- Rated Voltage: 6.3 V DC
- Case Size: 0603 (1.6 mm × 0.85 mm)
- Low ESR: Approximately 9 Ω
- Wide Operating Temperature Range: −55 °C to +125 °C
- Compact molded SMD package
- RoHS-compliant and halogen-free
- Available in Tape & Reel, Cut Tape, Digi-Reel packaging
Applications
- Decoupling and filtering in power supply circuits
- Voltage stabilization in portable and compact electronics
- Noise suppression in microcontroller and RF circuits
- General-purpose SMD usage where board space is limited
Specification
s| Parameter | Details |
|---|---|
| Capacitance | 10 µF ±20% |
| Voltage Rating | 6.3 V DC |
| Equivalent Series Resistance (ESR) | ~9 Ω |
| Package Size | 0603 (1.6 mm × 0.85 mm) |
| Height | ~0.8 mm |
| Operating Temperature | −55 °C to +125 °C |
| Compliance | RoHS, halogen-free |
