The USB 3.0 Type B Male 9-Pin Right Angle Connector is designed for high-speed data transmission and reliable connectivity in industrial and consumer electronics. Engineered with a right-angle form factor, this connector is ideal for use in space-restricted environments where standard straight connectors may not fit. Supporting data transfer speeds up to 5 Gbps, it ensures fast communication between devices, making it perfect for high-performance
Features
- High-Speed Data Transfer: Compliant with USB 3.0 standards, offering up to 5 Gbps data transfer rate.
- Right Angle Design: Ideal for compact spaces, making connections more convenient and reducing strain on cables.
- 9-Pin Configuration: Ensures full USB 3.0 functionality, including power and ground connections.
- Backward Compatibility: Compatible with USB 2.0 Type B devices, though limited to USB 2.0 speeds when connected to a USB 2.0 port.
- Durable Construction: Made from high-quality materials to withstand frequent connections and disconnections.
- Secure Connection: Ensures a stable connection for data and power transmission.
Applications
Specification
| Feature | Value |
|---|---|
| Connector Type | USB 3.0 Type B Male |
| Pins | 9 |
| Orientation | Right Angle |
| Data Transfer Rate | Up to 5 Gbps |
| Compatibility | USB 3.0 (backwards compatible with USB 2.0) |
| Material | High-quality, durable materials |
| Voltage Rating | 5V |
| Operating Temperature | -20°C to +85°C |
| Insertion Cycles | >10,000 |
| Applications | External storage, printers, scanners, industrial and medical equipment |
